7x14 Dump Trailers

7x14 Dump Trailers

At Top Shelf Trailers, we specialize in creating robust and reliable 7x14 dump trailers. Engineered with precision and designed for durability, our trailers are built to handle the toughest jobs

7x14 Dump Trailer Specifications

  • Size:  7x14 with 2 3 4 5 or 6 foot wall heights available
  • Capacity: 14,000 lbs 16,000 lbs or 20,000 lbs
  • Main Frame:  8 in I beam on 14 foot and longer
  • Tongue :   8 inch c channel full wrapped to axles for double frame strength and stability
  • Walls and Floor:   10 gage standard (Optional 7 gage)
  • Jack:   12,000 spring assisted manual ( Optional Powered Hydraulic Jack)
  • Crossmembers: 3 x 4.1 lb structural channel on 16" ( Most use formed)
  • Bed Hinges: We Use 4 lower bed hinges for more body stability dumping
  • Coupler:   Adjustable Channel with removeable 2 5/16 coupler
  • Stake Pockets:  Stake Pockets on Front and both sides
  • Fenders: HD Steel Tread Plate Braced for standing on
  • Steps: Steps welded to both sides ahead of fenders
  • Door Locks: Dual Rear Door Cam Locks on all 4 foot foot dump trailers
  • Storage: Large Locking Box for hydraulic pump Batteries and controls
  • Suspension:  2 inch Slipper Springs with greaseable center bolt
  • Axles: Lippert HD Quick Lube Tube Axles with Vaulcrum Caps
  • Axle Capacity: Dual 7000 lb capacity, with an option to upgrade to 8000 lb or 10,000 lb. axles.
  • Hydraulics: Three stage telescopic standard ( Optional Dual Cylinder No Charge) High Volume 12volt pump with pendant remote
  • Battery: Continental brand Deep cycle dual post batterrys
  • Charging:  Solar panel 120volt ac panel charger in the box and 12 volts from your trucks 7 way plug with our exclusive Truck Protection Circuit on all dump trailers.
  • Lighting: All lights are lifetime warranted LEDS
  • Wiring: Sealco Brand factory made and sealed wiring harness


   We at Top Shelf Trailers offer the best dump trailer after the sale experience available, we answer our phones 7 days a week from 8 PM till 9 PM, (Weekends and nights you may have to leave a message, messages are usually responded to in under an hour.)





Versatility and Customization

We understand that every job is unique, which is why we offer a range of additional options to customize your trailer. From upgrading the 10-ply to 14 Ply Tires, raising the side height in increments of 12", to adding a heavy charge cable to the trailer and truck, we provide the flexibility to tailor the trailer to your specific needs.


Sizes for Every Job

We offer our 7x14 dump trailers in both bumper pull and gooseneck configurations, ensuring we have the right solution for your hauling needs.

In addition to the 7x14 size, we also offer 7x12, 7x16, 7x18, 8x14, and 8x16 sizes, providing a range of options to suit any job size.

We dump what theirs can't

At Top Shelf Trailers, we choose to use Direct Push (Twin or Single Telescopic Cylinder) over scissor-style hoists in most applications because they provide a more powerful lifting system. Our twin Cylinder systems can dump payloads well over 15,000lbs, providing superior dumping capacity if you accidentally overload your trailer. This makes our trailers a reliable choice for large projects.
